Remote Networks: Service IP Address and Egress IP Address Allocation

How Prisma Access provides language localization for remote networks using egress IP addresses.
Where Can I Use This?What Do I Need?
  • Prisma Access (Managed by Panorama)
  • Prisma Access license
Prisma Access has more than 100 locations available to accommodate worldwide deployments and provide a localized experience. Two locations might map to the same , which you use as the peer IP address when you set up the IPSec tunnel for the remote network connection. However, the locations might use different egress IP addresses to make sure that the user gets the correct default language for the region.
Service connections do not support language localization because egress to the internet is not supported over service connections. Prisma Access allocates only one service IP address per service connection, and that IP address is geographically registered to the compute location that corresponds to the location you specify during onboarding.
The following example shows a customer deployment with two remote network locations deployed in Canada: Central Canada and Canada East. Prisma Access assigned the same Service IP Address to both locations. When you configure the remote network tunnel, use this IP address as the peer IP address when you create the IPSec tunnel for the remote network connection.
However, Canada East uses a different default language (French) than Central Canada (English). For this reason, Prisma Access assigns them different egress IP addresses. If you run the API script for egress IP addresses, you will receive two different IP addresses for these two locations.
