Connect AC Power to an M-300 or M-700
Appliance
Expand all | Collapse all
Connect AC Power to an M-300 or M-700
Appliance
Learn how to connect AC power to an M-300 or M-700 appliance.
The following procedure describes how to connect
AC power to an M-300 or M-700 appliance.
To
avoid injury to yourself or damage to your Palo Alto Networks® hardware
or the data that resides on the hardware, read the
Product Safety Warnings.
Plug two AC power cables (provided) in to grounded
wall outlets.
Connect the second power cord through
a different circuit breaker to provide power redundancy and to allow
for electrical circuit maintenance.
Insert one power cord in to each of the two power supplies
on the back of the appliance.
Press the power button on the front of the appliance.
If only one power supply is connected, a warning
beep will sound.
