Migrate Panorama to a FW-Flex License
Complete the following procedure to migrate
your VM-ELA or perpetual virtual Panorama license to a FW-Flex license.
This migration allows you to move your existing Panorama devices
to the FW-Flex license without disruption while retaining your existing
serial number. Because your serial number does not change, your
logs and existing policy are retained.
- Select AssetsSoftware NGFW Credits and click the Details button on the credit pool you used to create your profile.
- On the far right, select the vertical ellipsis (More
Options) and select Provision Panorama and
then click Migrate Existing.The CSP displays all virtual Panorama devices associated with your support account.
- Select the check box for each virtual Panorama to be migrated.
- Click Migrate.Verify that the Current Support Expiration Date has been updated. Additionally, you can expand each line to view the individual licenses applied to the selected Panorama.
![]()
